Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
161	P-1010-1 (DG)	TH Bobbin	RM-10	PM9630	1	6x6	ø0.6	18.0 / 21.6 / 25.2	3.6 / 7.2	DG	2
162	P-1010-2 (DG)	TH Bobbin	RM-10	PM9630	1	6x6	ø0.6	18.0 / 21.6 / 25.2	3.6 / 7.2	DG	2
163	P-1010-3 (DG)	TH Bobbin	RM-10	PM9630	1	6x6	0.5x0.5	18.0 / 21.6 / 25.2	3.6 / 7.2	DG	0
164	P-1014 (DG)	TH Bobbin	RM-10	PM9630	2	6x6	ø0.6	18.0 / 21.6 / 25.2	3.6 / 7.2	DG	1
165	P-1014-1 (DG)	TH Bobbin	RM-10	PM9630	2	6x6	0.5x0.5	18.0 / 21.6 / 25.2	3.6 / 7.2	DG	1
166	P-1016 (SZ)	TH Bobbin	RM-10	CP-J-8800 / PM9820	1					SZ	3
167	P-1017-2 (SZ)	TH Bobbin	RM-10	PM9820	1	6x6	ø0.6	17.96 / 21.55 / 25.14	3.59 / 7.18	SZ	2
168	P-1019-1 (SZ)	TH Bobbin	UU-09.8	T375J	2	2x2	ø0.6	8.0	7.0	SZ	0
169	P-1023 (DG)	TH Bobbin	RM-10	CP-J-8800	1	4	ø0.8		3.5	DG	0
170	P-1025 (SZ)	TH Bobbin	EE-10.2	LCP E4008	1	2x2	ø0.6 / ø1.0	9.5	7.5 / 5.0	SZ	1
171	P-1026 (SZ)	TH Bobbin	EE-10.2	PET FR530	1	2x2	ø0.6 / ø1.0	9.5	7.5 / 5.0	SZ	0
172	P-1031 (DG)	T-H BOBBIN	RM-10	PM9630	1	5	ø0.8		3.5	DG	4
173	P-1032 (DG)	TH Bobbin	RM-10	PM9630	1	6	ø0.6		3.6 / 7.2	DG	0
174	P-1036 (ZZ)	TH Bobbin	RM-10	PM9820	1	3x5	ø0.8	25.0	5.0 / 3.5	ZZ	1
175	P-1039 (ZZ)	TH Bobbin	RM-10	PM9820	1	5	ø0.8		3.5	ZZ	2
176	P-1041 (DG)	TH Bobbin	EE-10	PM9630	1	5x5	0.5x0.5	15.0/11.0	2.5	DG	0
177	P-1101 (DG)	TH Bobbin	POT-1107	PET FR530	1					DG	0
178	P-1201 (DG)	TH Bobbin	EF-12.6	PET FR530	1	3x3	0.5x0.5	7.6	3.8	DG	5
179	P-1201-1 (DG)	TH Bobbin	EF-12.6	PET FR530	1	3x3	0.5x0.5	7.6	3.8	DG	0
180	P-1201-3 (DG)	TH Bobbin	EF-12.6	PM9820	1	3x3	0.5x0.5	7.6	5.0 / 4.3	DG	0
