Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
581	P-3004-10 (DG)	TH Bobbin	EFD-30	PM9820	1	6x6	ø0.8	27.5	5.0	DG	0
582	P-3004-2 (DG)	TH Bobbin	EFD-30	PM9630	1	6x6	ø0.7	27.5	5.0	DG	4
583	P-3004-6 (DG)	TH Bobbin	EFD-30	PM9820	1	6x6	ø0.8	27.5	5.0	DG	4
584	P-3004-7 (DG)	TH Bobbin	EFD-30	PM9823J	1	6x6	ø0.8	27.5	5.0	DG	0
585	P-3004-9 (DG)	TH Bobbin	EFD-30	PM9630 JT	1	6x6	ø0.8	27.5	5.0	DG	0
586	P-3006 (ZZ)	TH Bobbin	EE-30H	T375J	2	6x6	ø0.8	25.0	5.0	ZZ	2
587	P-3007-2 (SZ)	TH Bobbin	POT-3019	PM9820	1	5x5	ø0.8	28.0	5.0	SZ	2
588	P-3007-2 (ZZ)	TH Bobbin	POT-3019	PM9820	1	5x5	ø0.8	28.0	5.0	ZZ	2
589	P-3010 (SZ)	TH Bobbin	PJ-3018	CP-J-8800	1	5x5	0.7x0.4	27.94	5.1	SZ	2
590	P-3016 (SZ)	TH Bobbin	EFD-30	PM9820	1	6x6	ø0.8	33.5	5.0	SZ	1
591	P-3022-1 (SZ)	TH Bobbin	PJ-3021	PM9820	1	4x5	ø1.0	28.0	5.1	SZ	1
592	P-3036 (ZZ)	TH Bobbin	POT-3017	PM9820	1	5x4	ø0.8	28.0	5.0 / 6.75	ZZ	2
593	P-3201 (DG)	TH Bobbin	PQ-3220	PM9820	1	6x6	ø0.8	30.5	5.08 / 7.62	DG	3
594	P-3201-1 (DG)	TH Bobbin	PQ-3220	PM9820	1	6x6	ø0.8	30.5	5.1 / 7.6	DG	3
595	P-3201-3 (DG)	TH Bobbin	PQ-3220	PM9820	1	6x6	ø0.8	30.5	5.08 / 7.62	DG	1
596	P-3201-4 (DG)	TH Bobbin	PQ-3220	PM9820	1	6x6	ø0.8	30.5	5.08 / 7.62	DG	1
597	P-3201-5 (DG)	TH Bobbin	PQ-3220	PM9820	1	6x6	ø0.8	30.5	5.1 / 7.6	DG	2
598	P-3201-7 (DG)	TH Bobbin	PQ-3220	PM9630 JT	1	6x6	ø0.8	30.5	5.1 / 7.6	DG	0
599	P-3201-9 (DG)	TH Bobbin	PQ-3220	PM9820	1	6x6	ø0.8	30.5	5.08 / 7.62	DG	0
600	P-3202 (DG)	TH Bobbin	PQ-3225	PM9820	1	6x6	ø0.8	30.5	5.08 / 7.62	DG	1

页次：资料总数：1037
