Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
661	P-3918 (DG)	TH Bobbin	EER-39	PM9820	2	7x7	ø0.8	36.0	5.8	DG	2
662	P-3924 (SZ)	TH Bobbin	EER-39	T375J	1	8x8	ø1.0	25.0	5.0	SZ	1
663	P-4001 (DG)	TH Bobbin	EE-40	T375J	1	6x6	ø0.8	22.5	5.0	DG	4
664	P-4004 (DG)	TH Bobbin	EE-40	PM9820	3	8x8	ø0.8	22.5	5.0	DG	3
665	P-4005 (DG)	TH Bobbin	EER-40	PM9620 / PM9820 / PM9823 / T375J / CP-J-8800	1	8x8	ø1.0	35.0	5.0	DG	6
666	P-4005-2 (DG)	TH Bobbin	EER-40	T375HF	1	8x8	ø1.0	35.0	5.0	DG	0
667	P-4006 (DG)	TH Bobbin	EI-40	PET FR530	1	6x6	ø0.8	22.5	5.0	DG	4
668	P-4007 (DG)	TH Bobbin	EER-40	T375J	1	7x7	ø1.0	25.0	5.0	DG	2
669	P-4010 (SZ)	TH Bobbin	POT-4026	CP-J-8800 / T375HF	1	5	0.8x0.8		5.0	SZ	8
670	P-4010-3 (SZ)	TH Bobbin	POT-4020	PM9630	1	5x1	0.8x0.8	38.9	5.0	SZ	5
671	P-4010-4 (ZZ)	TH Bobbin	POT-4026	CP-J-8800	1	5x1	0.8x0.8	33.5	5.0	ZZ	0
672	P-4011 (DG)	TH Bobbin	EE-40	PM9820	1	7x7	ø0.8	25.6	5.0	DG	2
673	P-4012 (DG)	TH Bobbin	EER-40	PM9820	1	19x19	ø0.8	35.0	3.0	DG	0
674	P-4101 (DG)	TH Bobbin	EI-41	PA66 70G33L	1	7x7	ø0.8	23.6	5.08	DG	6
675	P-4203 (DG)	TH Bobbin	EE-4215	PBT 4130	1	8x8	ø0.8	36.0	5.0	DG	4
676	P-4204 (DG)	TH Bobbin	EE-4220	T375J	1	6x6	ø1.0	32.5	5.0	DG	1
677	P-4204-2 (DG)	TH Bobbin	EE-4220	T375HF	1	6x6	ø1.0	32.5	5.0	DG	0
678	P-4205 (DG)	TH Bobbin	EE-4215V	T375J	1	9x9	ø1.0	27.5	5.0	DG	5
679	P-4205-1 (SZ)	TH Bobbin	EE-4215V	T375J	1	9x9	ø1.0	27.5	5.0	SZ	0
680	P-4206 (ZZ)	TH Bobbin	ER-4215	T375J	1	7x7	ø1.0	25.0	5.0	ZZ	4
