Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
681	P-4208-1 (DG)	TH Bobbin	EE-4215H	PET FR530	1	8x8	ø1.0	37.9	7.5 / 5.0	DG	3
682	P-4209 (DG)	TH Bobbin	EE-4215V	T375J	1	9x9	ø1.0	27.5	5.0	DG	3
683	P-4210 (DG)	TH Bobbin	EE-4215V	T375J	1	9x9	ø1.0	25.0	5.0	DG	3
684	P-4211 (DG)	TH Bobbin	EE-4220	T375J / PM9820	1	6x6	ø1.0	32.5	5.0	DG	2
685	P-4211-1 (DG)	TH Bobbin	EE-4220	T375HF BK	1	6x6	ø1.0	32.5	5	DG	0
686	P-4216 (DG)	TH Bobbin	EE-4220	PET FR530	1	9x8	ø1.0	37.6	2.5 / 5.0	DG	3
687	P-4222-1 (SZ)	TH Bobbin	EE-4215L	PM9630	2	7x7	ø0.8	43.2	6.1	SZ	0
688	P-4223 (SZ)	TH Bobbin	EER-4215	PM9820 / PM9823 / T375HF	1	9x9	ø1.0	27.5	5.0	SZ	2
689	P-4229 (DG)	TH Bobbin	EE-4220	PA66 70G33L	1	6x6	1.0x1.0	35.0	5.0	DG	1
690	P-4229-1 (DG)	TH Bobbin	EE-4220	PA66 FR50 (BK)	1	6x6	1.0x1.0	35.0	5.0	DG	0
691	P-4229-2 (DG)	TH Bobbin	EE-4220	PET FR530	1	6x6	1.0x1.0	35	5.0	DG	0
692	P-4301-1 (SZ)	TH Bobbin	EFD-43	T375HF / PM9820	2	7x5	0.8x0.8	65.4	6.0	SZ	2
693	P-4403 (SZ)	TH Bobbin	ETD-44	PET FR530	1	9x9	0.8x0.8	35.56	5.08	SZ	2
694	P-4502-1 (SZ)	TH Bobbin	EFD-45	T375J	2	5x7	0.8x0.8	52.2	6.0	SZ	5
695	P-4502-2 (SZ)	TH Bobbin	EFD-45	PM9820	1	5x7	0.8x0.8	54.4	6.0	SZ	4
696	P-4502-4 (SZ)	TH Bobbin	EFD-45	T375J	2	5x7	0.8x0.8	52.2	6.0	SZ	0
697	P-4901 (DG)	TH Bobbin	ETD-49	PM9820 JR	1	10x10	ø0.8	40.64	5.08	DG	4
698	P-4901-1 (DG)	TH Bobbin	ETD-49	PM9630 JT	1	10x10	ø0.8	40.64	5.08	DG	0
699	P-4902 (SZ)	TH Bobbin	ETD-49	PET FR530	1	10x10	0.8x0.8	40.64	5.08	SZ	1
700	P-4905-1 (SZ)	TH Bobbin	EER-49	PM9820	2	7x7	ø1.0	41.6	7.0	SZ	0

页次：资料总数：1037
