Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
401	P-2039-3 (SZ)	TH Bobbin	EF-20	PA66 FR50	1	3x3	0.64x0.64	10.0	5.08	SZ	1
402	P-2040 (DG)	TH Bobbin	EF-20	PET FR530 / PA66 A3X2G7	2	2x2	0.64x0.64	15.0	10.16	DG	3
403	P-2040-1 (DG)	TH Bobbin	EF-20	PET FR530 / PA66 A3X2G7	2	2x2	0.64x0.64	15.0	10.16	DG	0
404	P-2050 (SZ)	TH Bobbin	EQ-20	PM9630	1	4x6	0.64x0.64	32.6	3.6	SZ	2
405	P-2052 (SZ)	TH Bobbin	EQ-20	PM9630	1	3x3	0.6x0.6	26.3	6.0 / 6.5	SZ	2
406	P-2202 (ZZ)	TH Bobbin	EI-22	T375J	1	5x5	ø0.8	10.3	4.0	ZZ	2
407	P-2202-3 (ZZ)	TH Bobbin	EI-22	T375J	1	5x5	ø0.8	12.0	4.0	ZZ	1
408	P-2202-4 (ZZ)	TH Bobbin	EI-22	T375J	1	5x5	ø0.8	10.0	4.0	ZZ	3
409	P-2202-6 (SZ)	TH Bobbin	EI-22	T375J / T375HF	1	5x5	ø0.8	10.3	4.0	SZ	4
410	P-2202-7 (SZ)	TH Bobbin	EI-22	T375HF	1	5x5	ø0.8	10.0	4.0	SZ	2
411	P-2202-8 (ZZ)	TH Bobbin	EI-22	T375J	1	5x5	ø0.8	10.3	4.0	ZZ	0
412	P-2204 (DG)	TH Bobbin	EEL-22	T355J	1	5x5	ø0.8	15.0	4.75 / 3.75	DG	2
413	P-2204-1 (DG)	TH Bobbin	EEL-22	PM9823 J	1	5x5	ø0.8	15.0	4.75 / 3.75	DG	0
414	P-2207 (DG)	TH Bobbin	EI-22	PM9820	1	5x4	ø0.8	17.0	4.0 / 3.5 / 5.0	DG	2
415	P-2208 (ZZ)	TH Bobbin	EI-22	T355J	1	5x4	ø0.7	12.7	3.81 / 7.62	ZZ	0
416	P-2209 (SZ)	TH Bobbin	EI-22	T375HF	1	4x4	ø0.8	12.5	5.0	SZ	5
417	P-2212-1 (DG)	TH Bobbin	EI-22	T375J	1	5x5	ø0.8	11.4	4.0	DG	0
418	P-2217 (SZ)	TH Bobbin	EE-22	PM9630 / PM9820	1	5x4	ø0.8	17.0	4.0 / 5.0	SZ	3
419	P-2218 (SZ)	TH Bobbin	EE-22	PM9820 / T375HF / AM113 / PM9630	1	9x9	ø0.6	12.5	2.5	SZ	4
420	P-2301 (DG)	TH Bobbin	POT-2311	PM9820	1	5x5	0.7x0.4	20.32	3.81	DG	1
