Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
381	P-2016 (DG)	TH Bobbin	EP-20	T355J	1	5x5	0.5x0.5	17.78	5.08	DG	1
382	P-2019-1 (DG)	TH Base	ET-20H	T375HF BK		2x2	ø0.8	13	17	DG	0
383	P-2020 (DG)	TH Bobbin	EF-20	PET FR530	1	3x3	0.64x0.64	15.0	5.08	DG	4
384	P-2020-1 (DG)	TH Bobbin	EF-20	PA66 A3X2G7	1	3x3	0.64x0.64	15.0	5.08	DG	5
385	P-2022 (ZZ)	TH Bobbin	EFD-20	PM9630	1	4x4	ø0.6	17.5	5.0	ZZ	1
386	P-2022-1 (ZZ)	TH Bobbin	EFD-20	PM9820	1	4x4	0.5x0.5	17.5	5.0	ZZ	0
387	P-2022-2 (ZZ)	TH Bobbin	EFD-20	PM9630	1	4x4	ø0.6	17.5	5.0	ZZ	1
388	P-2026-1 (SZ)	TH Bobbin	EF-20H	T375J	1	4x4	ø0.7	15.0	5.0	SZ	0
389	P-2027 (ZZ)	TH Bobbin	EF-20	CP-J-8800	1	4x4	ø0.7	15.0	5.0	ZZ	3
390	P-2030 (SZ)	TH Bobbin	EF-20	PA66 A3X2G7 / PET FR530	1	5x5	0.5x0.5	10.16	3.81	SZ	1
391	P-2030-1 (DG)	TH Bobbin	EF-20	DAP AM113	1	5x5	0.7x0.7	10.16	3.81	DG	5
392	P-2030-3 (DG)	TH Bobbin	EF-20	WH9100HM	1	5x5	0.7x0.7	10.16	3.81	DG	0
393	P-2031 (SZ)	TH Bobbin	EF-20	PA66 A3X2G7 / PBT420SE0 / A3X2G5 / PET FR530 / PA66 A20V35	1	5x5	0.5x0.5	15.24	3.81	SZ	4
394	P-2031-1 (SZ)	TH Bobbin	EF-20	PA66 A3X2G7	1	5x5	0.64x0.64	15.24	3.81	SZ	0
395	P-2032 (SZ)	TH Bobbin	EFD-20	LCP E4008	1	5x5	1.0x0.35	21.3 / 27.5	3.75	SZ	1
396	P-2032-1 (SZ)	TH Bobbin	EFD-20	LCP E4008	1	5x5	1.0x0.35	21.25	3.75	SZ	1
397	P-2034 (DG)	TH Bobbin	EF-20	PET FR530	1	3x3	0.64x0.64	10.0	5.0	DG	5
398	P-2036 (DG)	TH Bobbin	PQ-2020	PM9820	1	6x8	ø0.6	20.35	3.8 / 2.54 / 5.0	DG	10
399	P-2039-1 (SZ)	TH Bobbin	EF-20	PA66 FR50 / PET FR530	1	3x3	0.64x0.64	10.0	5.08	SZ	2
400	P-2039-2 (SZ)	TH Bobbin	EF-20	PA66 FR50	2	3x3	0.64x0.64	10.0	5.08	SZ	1
