Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
361	P-2011 (DG)	TH Base	ET-20V	T375J		2x2	ø0.8	10.0	13.0	DG	2
362	P-2012 (DG)	TH Bobbin	EF-20H	T375J	1	4x4	ø0.7	15.04	5.0	DG	4
363	P-2012-1 (DG)	TH Bobbin	EF-20H	T375J	2	4x4	ø0.7	15.0	5.0	DG	3
364	P-2012-3 (DG)	TH Bobbin	EF-20H	T375HF	2	4x4	ø0.7	15.0	5.0	DG	1
365	P-2013 (DG)	TH Bobbin	PQ-2016	PM9820	1	6x8	ø0.6	20.32	3.8 / 2.54 / 5.0	DG	1
366	P-2014 (DG)	TH Bobbin	EF-20	T355J	2	5x5	ø0.8	15.24	3.8	DG	2
367	P-2014-2 (DG)	TH Bobbin	EF-20	T375HF BK	2	5x5	ø0.8	15.24	3.8	DG	0
368	P-2015 (DG)	TH Bobbin	EF-20	PM9820	1	5x5	ø0.8	15.24	3.8	DG	5
369	P-2015 (ZZ)	TH Bobbin	EF-20	PM9820	1	5x5	ø0.8	15.24	3.8	ZZ	5
370	P-2015-1 (DG)	TH Bobbin	EF-20	PM9820	1	5x5	0.64x0.64	15.24	3.8	DG	4
371	P-2015-1 (ZZ)	TH Bobbin	EF-20	PM9820	1	5x5	0.64x0.64	15.24	3.8	ZZ	4
372	P-2015-10 (DG)	TH Bobbin	EF-20	PM-9630JT BK	1	5x5	0.5x0.5	15.24	3.8	DG	0
373	P-2015-11 (DG)	TH Bobbin	EF-20	T375HF BK	1	5x5	ø0.8	15.24	3.8	DG	0
374	P-2015-2 (DG)	TH Bobbin	EF-20	PM9820	1	5x5	0.5x0.5	15.24	3.8	DG	1
375	P-2015-3 (DG)	TH Bobbin	EF-20	PM9820	1	5x5	ø0.8	15.24	3.81	DG	2
376	P-2015-4 (DG)	TH Bobbin	EF-20	PET FR530	1	5x5	0.64x0.64	15.24	3.81	DG	0
377	P-2015-5 (DG)	TH Bobbin	EF-20	PM9820	1	5x5	0.45x0.45	15.24	3.8	DG	0
378	P-2015-7 (DG)	TH Bobbin	EF-20	PM9820	1	5x5	0.64x0.64	15.24	3.8	DG	0
379	P-2015-8 (DG)	TH Bobbin	EF-20	PM9820	1	5x5	ø0.8	15.24	3.8	DG	0
380	P-2015-9 (DG)	TH Bobbin	EF-20	DAP WH9100HM-P	1	5X5	0.5x0.5	15.24	3.8	DG	0
