Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
421	P-2302 (DG)	TH Bobbin	POT-2311	PM9630	1	5x5	0.64x0.64	20.3	3.81	DG	1
422	P-2304-1 (SZ)	TH Bobbin	PJ-2311	T375J	1	5x5	0.7x0.7	46.1	3.8	SZ	3
423	P-2401 (SZ)	TH Bobbin	ET-24	PBT 1403G3	4					SZ	6
424	P-2401 (ZZ)	TH Bobbin	ET-24	PBT 4115	4					ZZ	1
425	P-2403-1 (DG)	TH Base	ET-24H	T355J		2x2	ø0.8	15.0	21.0	DG	2
426	P-2405 (SZ)	TH Base	ET-24V	T375J		2x2	ø0.8	10.0	13.0	SZ	2
427	P-2405 (ZZ)	TH Base	ET-24V	T355J		2x2	ø0.8	10.0	13.0	ZZ	3
428	P-2407 (ZZ)	TH Base	ET-24H	T355J		2x2	ø0.8	21.0	15.0	ZZ	1
429	P-2407-1 (ZZ)	TH Base	ET-24H	T355J		2x2	ø0.8	15.0	21.0	ZZ	0
430	P-2408 (ZZ)	TH Base	ET-24V	T355J		2x2	ø0.8	10.0	16.5	ZZ	2
431	P-2409 (DG)	TH Base	ET-24V	T375J		3x3	ø0.8	10.0	6.5	DG	3
432	P-2410 (DG)	TH Bobbin	EI-24	T375J	1	3x3	ø0.7	17.5	5.0	DG	5
433	P-2410-2 (DG)	TH Bobbin	EI-24	T375HF	1	3x3	ø0.7	17.5	5.0	DG	0
434	P-2411 (ZZ)	TH Bobbin	EER-24.5	PM9820	1	5x5	ø0.8	17.5	5.0	ZZ	2
435	P-2501 (DG)	TH Bobbin	EF-25H	PET FR530	4	4x4	0.64x0.64	20.0	5.0	DG	3
436	P-2503 (DG)	TH Bobbin	EE-25H	PBT 4130	2	5x5	ø0.8	15.0	3.8 / 5.0	DG	2
437	P-2503-1 (DG)	TH Bobbin	EE-25H	PBT 4130	2	5x5	ø0.8	15.0	3.8 / 5.0	DG	1
438	P-2504 (DG)	TH Bobbin	EE-25V	PBT E202G30	2	2x2	ø0.8	15.0	14.0	DG	2
439	P-2505 (DG)	TH Bobbin	EF-25H	PET FR530	4	4x4	0.64x0.64	20.0	5.0	DG	3
440	P-2505-1 (DG)	TH Bobbin	EF-25H	PET FR530	4	4x4	0.64x0.64	20.0	5.0	DG	5
