Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
801	S-0706 (DG)	SMD Bobbin	EPX-7	DAP AM113	1	4x4	0.71x0.25	7.5 / 8.8	2.5	DG	5
802	S-0706-1 (DG)	SMD Bobbin	EPX-07	WH-9100HM	1	4x4	0.71x0.25	8.8	2.5	DG	1
803	S-0707 (DG)	SMD Bobbin	ER-7.5	LCP E4008	1	4x4	0.6x0.25	8.0 / 9.0	1.75	DG	3
804	S-0707-1 (DG)	SMD Bobbin	ER-7.5	PM9630	1	4x4	0.6x0.25	8.0 / 9.0	1.75	DG	3
805	S-0708 (DG)	SMD Bobbin	EP-07	PM9630	1	4x4	0.7x0.25	10.6 / 12.7	2.5	DG	3
806	S-0708-1 (DG)	SMD Bobbin	EP-07	DAP AM113	1	4x4	0.7x0.25	10.61 / 12.7	2.5	DG	3
807	S-0708-2 (DG)	SMD Bobbin	EP-07	PM9630	1	4x4	0.7x0.25	10.6 / 12.7	2.5	DG	2
808	S-0710 (DG)	SMD Bobbin	EP-07	LCP E4008	1	3x3	0.6x0.3	7.15 / 10.75 / 13.4	3	DG	3
809	S-0710-1 (DG)	SMD Bobbin	EP-07	PM9630	1	3x3	0.6x0.3	7.15 / 10.75 / 13.4	3	DG	2
810	S-0710-3 (DG)	SMD Bobbin	EP-07	PM9630	1	3x3	0.6x0.3	7.15 / 10.75 / 13.15	3	DG	0
811	S-0713 (SZ)	SMD Bobbin	EP-07	PM9630	1	4x4	0.7x0.3	6.1 / 8.6	2.5	SZ	2
812	S-0714 (DG)	SMD Bobbin	EP-07	PM9630	1	4x4	0.4x0.4	5.61 / 8.65	2.5	DG	11
813	S-0714-2 (DG)	SMD Bobbin	EP-07	PM9630	1	4x4	0.4x0.4	5.61 / 8.15	2.5	DG	0
814	S-0801 (DG)	SMD Bobbin	ED-08	LCP E4008	2	3x3	0.6x0.25	10.5 / 13.5	2.6	DG	2
815	S-0802 (DG)	SMD Bobbin	ED-08	LCP E4008	1	2x2	0.7x0.3	16.8 / 18.2	5.08	DG	2
816	S-0802-1 (DG)	SMD Bobbin	ED-08	LCP E4008	1	2x2	0.7x0.3	16.0 / 18.2	5.08	DG	1
817	S-0802-2 (DG)	SMD Bobbin	ED-08	LCP E4008	1	2x2	0.7x0.3	16.8 / 18.2	5.08	DG	2
818	S-0803 (DG)	SMD Bobbin	ED-08	LCP E4008	1	2x2	0.7x0.3	18.6 / 20.0	5.08	DG	3
819	S-0803-1 (DG)	SMD Bobbin	ED-08	LCP E4008	1	2x2	0.7x0.3	18.7 / 20.4	5.08	DG	0
820	S-0809-1 (DG)	SMD Bobbin	EE-08.8	PM9630	2	4x4	0.6x0.3	10.82 / 12.2	2.54	DG	0
