Bobbin & Base

Enter one or more of the options below in search of bobbin & base:

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
821	S-0809-1 (SZ)	SMD Bobbin	EE-08.8	PM9630	2	4x4	0.6x0.3	10.82 / 12.2	2.54	SZ	7
822	S-0809-2 (DG)	SMD Bobbin	EE-08.8	PM9630	1	4x4	0.6x0.3	11.1 / 12.2	2.54	DG	2
823	S-0809-2 (SZ)	SMD Bobbin	EE-08.8	PM9630	1	4x4	0.6x0.3	11.1 / 12.2	2.54	SZ	2
824	S-0809-3 (SZ)	SMD Bobbin	EE-08.8	PM9630	2	4x4	0.6x0.3	11.1 / 12.2	2.54	SZ	1
825	S-0809-6 (SZ)	SMD Bobbin	EE-08.8	PM9630	1	4x4	0.6x0.3	10.8 / 12.2	2.54	SZ	0
826	S-0812 (DG)	SMD Bobbin	ED-08	LCP E4008	1	3x3	0.63x0.3	11.7 / 12.7	2.54	DG	0
827	S-0813 (DG)	SMD Bobbin	ED-08	LCP E4008	2	3x3	0.64x0.3	11.2 / 14.5	2.54	DG	1
828	S-0815 (DG)	SMD Bobbin	EE-08.3	PM9820	2	2x2	0.7x0.3	12	5	DG	1
829	S-0815-1 (DG)	SMD Bobbin	EE-08.3	PM9630	2	2x2	0.7x0.3	10.8 / 12.8	5	DG	0
830	S-0820-1 (SZ)	SMD Bobbin	CI-08.5	LCP E4008	10	3x4	0.7x0.25 / 0.5x0.25	35.2 / 36.4 / 38.1	2.0 / 1.7 / 5.0	SZ	6
831	S-0820-7 (SZ)	SMD Bobbin	CI-08.5	LCP E4008	10	3x4	0.7x0.3 / 1.0x0.3	36.4 / 38.1	2.0 / 1.7	SZ	3
832	S-0822-8 (SZ)	SMD Bobbin	CI-08.5	LCP E4008	10	4x3	0.7x0.3 / 1.0x0.3	38.1	2.0 / 1.7 / 5.0	SZ	2
833	S-0825 (DG)	SMD Bobbin	EE-08.8	LCP E4008	3	2x2	0.5x0.2	13.8 / 15.0	6.5	DG	1
834	S-0825-1 (SZ)	SMD Bobbin	EE-08.8	LCP E4008	1	2x2	0.5x0.2	13.8 / 15.0	6.5	SZ	1
835	S-0828-1 (SZ)	SMD Bobbin	CI-08.1	LCP E4008	12	3x2	0.5x0.3	37.5 / 40.0	2.0 / 1.7 / 5.0	SZ	10
836	S-0828-5 (SZ)	SMD Bobbin	CI-08.1	LCP E4008	12	3x2	0.5x0.3 / 0.7x0.3	37.5 / 40.0	2.0 / 1.7 / 5.0	SZ	3
837	S-0828-7 (SZ)	SMD Bobbin	CI-08.1	LCP E4008	12	3x2	0.5x0.3 / 0.7x0.3	37.5 / 40.0	2.0 / 1.7 / 5.0	SZ	3
838	S-0830 (DG)	SMD Bobbin	EE-08	PM9630	1	4x4	0.6x0.3	11.3 / 12.2	2.54	DG	2
839	S-0833-5 (SZ)	SMD Bobbin	EE-08.3	LCP E4008	2	2x2	0.7x0.3	13.8	5	SZ	0
840	S-0837-1 (SZ)	SMD Bobbin	CI-08.8	LCP E4008	8	2x3	0.7x0.3 / 0.9x0.3	36.4 / 38.1	2.0 / 1.7 / 5.05	SZ	4

次へ: 資料総計:1033
