Bobbin & Base

Enter one or more of the options below in search of bobbin & base:

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
841	S-0838-3 (SZ)	SMD Bobbin	CI-08.8	LCP E4008	8	3x4	0.7x0.3 / 1.0x0.3	38.1	2.0 / 1.7 / 5.0	SZ	1
842	S-0900 (DG)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.7x0.25	10.1 / 11.55	2	DG	2
843	S-0900 (SZ)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.7x0.25	10.1 / 11.55	2	SZ	1
844	S-0900-1 (DG)	SMD Bobbin	ER-0905	PM9630(BK)	1	4x4	0.7x0.25	10.1 / 11.55	2	DG	2
845	S-0900-3 (DG)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.7x0.25	9.4 / 10.8	2	DG	1
846	S-0900-4 (DG)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.7x0.25	10.1 / 13.25	2	DG	1
847	S-0900-5 (DG)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.7x0.25	10.4 / 11.55	2	DG	0
848	S-0900-6 (DG)	SMD Bobbin	ER-0905	PM9630	1	4x4	0.7x0.25	10.4 / 11.55	2	DG	0
849	S-0900-7 (DG)	SMD Bobbin	ER-0905	PM9630	1	4x4	0.7x0.25	10.1 / 11.55	2	DG	0
850	S-0900-8 (SZ)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.7x0.25	11.95	2	SZ	0
851	S-0902-1 (SZ)	SMD Bobbin	UI-09.8-C	LCP E4008	8	5x3	0.5x0.3	30.1 / 32.1	1.45 / 6.1 / 1.6	SZ	7
852	S-0902-3 (DG)	SMD Bobbin	UI-09.8-C	LCP E4008	8	5x3	0.5x0.3	30.4 / 32.0	1.45 / 6.1 / 1.6	DG	9
853	S-0902-5 (SZ)	SMD Bobbin	UI-09.8-C	LCP E4008	8	5x3	0.5x0.3	32.1	1.45 / 6.1 / 1.6	SZ	6
854	S-0903 (DG)	SMD Bobbin	FRAME-09	LCP E4008	6	6x2	0.4x0.4	35.0 / 36.0	1.6 / 0.8	DG	2
855	S-0904 (DG)	SMD Bobbin	ER-0905	PM9630	1	4x4	0.4x0.4	6.33 / 12.0	2.54	DG	2
856	S-0904-1 (DG)	SMD Bobbin	ER-0905	PM9630	1	4x4	0.5x0.5	6.33 / 12.0	2.54	DG	2
857	S-0904-2 (DG)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.5x0.5	6.33 / 12.0	2.54	DG	2
858	S-0906 (DG)	SMD Bobbin	EPX-9	PM9630	1	4x4	0.5x0.5	6.86 / 9.65	2.5	DG	1
859	S-0907 (SZ)	SMD Bobbin	ER-0905	LCP E4008	1	4x4	0.7x0.25	10.45 / 11.6	2	SZ	1
860	S-0914-1 (SZ)	SMD Bobbin	UI-09.8-C	LCP E4008	8	5x3	0.5x0.3	30.1 / 32.1	1.45 / 6.1 / 1.6	SZ	4

次へ: 資料総計:1033
