Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
461	P-2520 (ZZ)	TH Bobbin	EF-25	T375J	1	4x4	ø0.8	20.0	5.0	ZZ	4
462	P-2521 (DG)	TH Bobbin	EFD-25	PM9820	1	5x5	ø0.7	22.5	5.0	DG	1
463	P-2521-1 (DG)	TH Bobbin	EFD-25	PM9630	4	5x5	0.6x0.6	22.5	5.0	DG	2
464	P-2521-2 (DG)	TH Bobbin	EFD-25	PM9630	1	5x5	ø0.7	22.5	5.0	DG	2
465	P-2521-3 (DG)	TH Bobbin	EFD-25	PM9630	1	5x5	0.6x0.6	22.5	5.0	DG	1
466	P-2523 (DG)	TH Bobbin	EPC-25	T375J / T375HF	1	5x6	ø0.8	20.0	5.0 / 3.76	DG	2
467	P-2523-1 (SZ)	TH Bobbin	EPC-25	T375HF	1	5x6	ø0.8	20.0	5.0 / 3.75	SZ	2
468	P-2523-2 (DG)	TH Bobbin	EPC-25	T375HF BK	1	5x6	ø0.8	20.0	5.0 / 3.76	DG	0
469	P-2524 (DG)	TH Bobbin	EI-25	T375J	1	5x5	ø0.8	15.2	5.0	DG	2
470	P-2524-1 (DG)	TH Bobbin	EI-25	PM9823 J	1	5x5	ø0.8	15.2	5.0	DG	0
471	P-2525 (DG)	TH Bobbin	EFD-25	PM9820	1	5x5	ø0.7	22.5	5.0	DG	1
472	P-2526 (DG)	TH Bobbin	EFD-25	PM9820	1	5x5	ø0.7	22.5	5.0	DG	5
473	P-2526-1 (DG)	TH Bobbin	EFD-25	PM9820	4	5x5	0.6x0.6	22.5	5.0	DG	3
474	P-2528 (ZZ)	TH Bobbin	EF-25	T375J	1	4x4	ø0.8	.24.0	5.0	ZZ	3
475	P-2532 (DG)	TH Bobbin	EV-2513H	PET FR530	1	4x4	0.64x0.64	20.0	5.0	DG	2
476	P-2532-2 (DG)	TH Bobbin	EV-2513	PET FR530	4	4x4	0.64x0.64	20.0	5.0	DG	3
477	P-2532-3 (SZ)	TH Bobbin	EV-2513H	PET FR530	1	4x4	0.64x0.64	20.0	5.0	SZ	1
478	P-2533-2 (SZ)	TH Bobbin	EV-2513H	PET FR530	4	4x4	0.64x0.64	20.0	5.0	SZ	0
479	P-2534 (DG)	TH Bobbin	EI-25	PM9820	1	5x5	ø0.8	20.0	5.0	DG	2
480	P-2534 (ZZ)	TH Bobbin	EI-25	PM9820	1	5x5	ø0.8	20.0	5.0	ZZ	2
