Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
481	P-2535 (DG)	TH Bobbin	EFD-25	T375J	1	5x5	ø0.8	22.5	5.0	DG	0
482	P-2535 (SZ)	TH Bobbin	EFD-25	T375J / T375HF	1	5x5	ø0.8	22.5	5.0	SZ	5
483	P-2535-1 (DG)	TH Bobbin	EFD-25	T375HF	1	5x5	ø0.8	22.5	5.0	DG	0
484	P-2536 (DG)	TH Bobbin	EFD-25	PM9820	4	5x5	0.6x0.6	22.5	5.0	DG	3
485	P-2536-2 (DG)	TH Bobbin	EFD-2554	PM9630 JT	4	5x5	0.6x0.6	22.5	5.0	DG	0
486	P-2538 (SZ)	TH Bobbin	EF-25	PM9820 / T375HF	1	4x4	ø0.8	20.0	5.0	SZ	5
487	P-2539 (DG)	TH Bobbin	EF-25	CP-J-8800	1	5x5	ø0.8	20.0	4.0	DG	0
488	P-2541-1 (SZ)	TH Bobbin	EF-25	PA66 70G33L	1	4x4	0.64x0.64	21.7	4.7	SZ	0
489	P-2543 (SZ)	TH Bobbin	EF-25	PA66 70G33L(NC)	1	5x5	0.64x0.64	20.0	5.0	SZ	5
490	P-2544 (SZ)	TH Bobbin	EF-25	PA66 70G33L(NC)	2	5x5	0.64x0.64	20.0	5.0	SZ	5
491	P-2545 (ZZ)	TH Bobbin	ER-25.5	T375J / PM9823	1	5x5	ø0.8	15.0	5.0	ZZ	1
492	P-2549 (DG)	TH Bobbin	EF-25	PA66 A3X2G7	1	5x5	0.64x0.64	12.7	5.08	DG	0
493	P-2549 (SZ)	TH Bobbin	EF-25	PET FR530	1	5x5	0.64x0.64	12.7	5.08	SZ	2
494	P-2550 (DG)	TH Bobbin	EF-25	PA66 A3X2G7	1	5x5	0.64x0.64	20.32	5.08	DG	2
495	P-2550 (SZ)	TH Bobbin	EF-25	PA66 A3X2G7 / PET FR530	1	5x5	0.64x0.64	20.32	5.08	SZ	2
496	P-2550-1 (DG)	TH Bobbin	EF-25	DAP AM113	1	5x5	0.64x0.64	20.32	5.08	DG	0
497	P-2550-7 (DG)	TH Bobbin	EF-25	PM 9630 BK	1	5x5	0.64x0.64	20.32	5.08	DG	0
498	P-2550-8 (DG)	TH Bobbin	EF-25	PM 9820 BK	1	5x5	0.64x0.64	20.32	5.08	DG	0
499	P-2553 (DG)	TH Bobbin	EF-25	PET FR530	1	3x3	0.64x0.64	12.5	5.0	DG	1
500	P-2554 (DG)	TH Bobbin	EEL-25	T375J	1	5x5	5.0	12.6	5.0	DG	0

页次：资料总数：1037
