Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
721	PB-014-1 (DG)	TH Base	27.0x14.0x11.0	T375HF BK	5x5	ø1.0	10.0	5	DG	0
722	PB-015-1 (DG)	TH Base	DR-15	T375J	2x2	ø1.0	10.0	10.0	DG	0
723	PB-017-1 (SZ)	TH Base	DR-15	T375J	3x2	ø1.0	5.0 / 10.0	5.5 / 5.7	SZ	0
724	PB-019 (DG)	TH Base	27.94x20.32x10.1	PBT 1403G3					DG	4
725	PB-019-1 (DG)	TH Base	27.94x20.32x10.1	PBT 1403G3					DG	2
726	PB-020 (DG)	TH Base	24.0x18.0x11.0	T375J / PM9820JT	5x5	ø1.0	14.0	5.0	DG	2
727	PB-022 (DG)	TH Base	10.1x8.75x5.0	DAP AM113	2x2	ø0.6	6.22	7.62	DG	4
728	PB-025 (DG)	TH Base	12.0x7.0x4.0	T375J	2x2	ø0.7	4.5	10.0	DG	3
729	PB-029 (DG)	TH Base	11.9x11.9x4.6	T375J	4x4	ø0.7	7.6	2.4 / 2.5	DG	1
730	PB-031 (DG)	TH Base	12.0x7.0x4.0	T375J	2x2	ø0.7	2.0	10.0	DG	4
731	PB-031-1 (DG)	TH Base	12.0x7.0x4.0	T375HF BK	2x2	ø0.7	2	10	DG	0
732	PB-033 (SZ)	TH Base	RM-10	CP-J-8800	4x2	ø0.8	27.0	3.5 / 5.0	SZ	1
733	PB-033-1 (SZ)	TH Base	RM-10	PM9630	4x2	ø0.8	27.0	3.5 / 5.0	SZ	0
734	PB-034 (SZ)	TH Base	RM-08	PM9630	4x2	ø0.8	19.5	3.5 / 18.0	SZ	1
735	PB-039 (DG)	TH Base	27.0x19.0x7.5	T375J					DG	0
736	PB-044 (DG)	Header	20.3x9.0x4.6	T375J	8x8	ø0.5	7.62	2.54	DG	2
737	PB-045 (SZ)	TH Base	CV-09	PM9820	4x2x4	ø0.5	9.4 / 15.22	4.94 / 4.0 / 1.53	SZ	0
738	PB-046 (DG)	Case/Cover	16.0x9.0x5.0	PM9820	2x4	0.6x0.8	20.0	5.0 / 15.0	DG	2
739	PB-053 (DG)	Case/Cover	PJ-3319	PM9820(BK)	2x2	0.64x0.64	13.46	7.36 / 13.40	DG	4
740	PB-053-1 (DG)	Case/Cover	PJ-3319	DAP WH9100 BK	2x2	0.64x0.64	13.46	7.36	DG	0
