Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
881	S-1101-4 (SZ)	SMD Bobbin	ER-1105	LCP E4008	1	5x5	0.7x0.25	10.7 / 12.2	2.0	SZ	5
882	S-1101-5 (DG)	SMD Bobbin	ER-1105	LCP E4008	1	5x5	0.7x0.25	11.0 / 12.2	2.0	DG	1
883	S-1101-8 (DG)	SMD Bobbin	ER-1105	HTN FR52G30NH	1	5x5	0.7x0.25	11.0 / 12.0	2.0	DG	0
884	S-1103 (DG)	SMD Bobbin	ER-1105	LCP E4008	1	6x6	0.7x0.3	11.0 / 12.2	2.0	DG	2
885	S-1103-2 (DG)	SMD Bobbin	ER-1105	PM9630	1	6x6	0.7x0.25	11.0 / 12.2	2.0	DG	0
886	S-1103-4 (DG)	SMD Bobbin	ER-1105	PM9630	1	6x6	0.7x0.25	13.4	2	DG	0
887	S-1106-2 (SZ)	SMD Bobbin	UI-11.7	LCP E4008	7	6x2	0.5x0.2	28.75	10.0 / 2.0	SZ	1
888	S-1201 (DG)	SMD Bobbin	EEM-12.7	LCP E4008	1	5x5	0.6x0.3	14.7 / 16.0	2.0	DG	0
889	S-1202 (DG)	SMD Bobbin	EF-12.6	PM9630	1	3x5	0.6x0.4	15.3 / 17.7	2.54	DG	1
890	S-1202-1 (DG)	SMD Bobbin	EF-12.6	PM9630	1	5x5	0.6x0.4	15.3 / 17.7	2.54	DG	1
891	S-1203-1 (DG)	SMD Bobbin	EE-12.6	PM9630	2	5x5	0.6x0.4	15.3 / 17.7	2.54	DG	2
892	S-1204 (DG)	SMD Bobbin	EE-12.6	PM9630	1	5x5	0.6x0.4	15.1 / 16.8 / 17.2	2.54	DG	3
893	S-1204-1 (DG)	SMD Bobbin	EF-12.6	LCP E4008	1	5x5	0.6x0.4	16.7 / 19.2	2.54	DG	2
894	S-1204-2 (DG)	SMD Bobbin	EE-12.6	PM9630	1	5x5	0.6x0.4	16.7 / 19.2	2.54	DG	2
895	S-1205 (DG)	SMD Bobbin	EFD-12	LCP E4008	1	4x4	0.8x0.3	13.4 / 16.5 / 20.0	3.0	DG	6
896	S-1207 (DG)	SMD Bobbin	EEM-12.7	LCP E4008	1	4x4	0.6x0.3	15.3 / 16.7	2.0	DG	2
897	S-1207-1 (DG)	SMD Bobbin	EEM-12.7	PM9630	1	4x4	0.6x0.3	15.3 / 16.7	2.0	DG	3
898	S-1208-1 (DG)	SMD Bobbin	EEM-12.7	PM9630	1	5x5	0.6x0.3	15.3 / 16.7	2.0	DG	2
899	S-1208-2 (SZ)	SMD Bobbin	EEM-12.7	LCP E4008	1	5x5	0.6x0.3	15.3 / 16.7	2.0	SZ	0
900	S-1208-3 (SZ)	SMD Bobbin	EEM-12.7	LCP E4008	1	5x5	0.6x0.3	15.3 / 16.7	2.0	SZ	1

次へ: 資料総計:1033
