Bobbin & Base

Enter one or more of the options below in search of bobbin & base:

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
921	S-1313-1 (SZ)	SMD Bobbin	EPC-13	LCP E4008	4	5x5	0.7x0.4	19.0	2.5	SZ	0
922	S-1313-5 (SZ)	SMD Bobbin	EPC-13	LCP E4008	4	2x5	0.7x0.4	17.2 / 19.5	2.5 / 10.0	SZ	0
923	S-1313-7 (SZ)	SMD Bobbin	EPC-13	LCP E4008	2	5x5	0.7x0.4	17.2 / 19.5	2.5	SZ	0
924	S-1315-1 (DG)	SMD Bobbin	EP-13	DAP AM113	1	8x8	0.6x0.4	14.65 / 16.42	1.7	DG	1
925	S-1315-2 (DG)	SMD Bobbin	EP-13	DAP AM113 / WH9100HM P	1	8x4	0.6x0.4	14.65 / 16.42	1.7 / 3.4	DG	3
926	S-1315-3 (DG)	SMD Bobbin	EP-13	DAP AM113	1	8x4	0.6x0.4	14.65 / 16.42	1.7 / 3.4	DG	5
927	S-1315-3 (SZ)	SMD Bobbin	EP-13	DAP AM113	1	8x4	0.6x0.4	14.65 / 16.42	1.7 / 3.4	SZ	3
928	S-1315-B (DG)	SMD Bobbin	EP-13	DAP AM113	1	6x6	0.6x0.4	14.65 / 16.42	1.7 / 3.4 / 5.4	DG	0
929	S-1315-C (DG)	SMD Bobbin	EP-13	DAP AM113	1	6x6	0.6x0.4	14.65 / 16.42	1.7 / 3.4 / 5.4	DG	0
930	S-1316 (ZZ)	SMD Bobbin	EP-13	PM9630	1	4x4	0.7x0.3	14.6	2.5	ZZ	0
931	S-1316-1 (ZZ)	SMD Bobbin	EP-13	PM9630	1	4x4	0.7x0.3	14.6	2.5	ZZ	0
932	S-1400 (DG)	SMD Bobbin	ER-1406	LCP E4008	1	5x5	0.7x0.35	14.6 / 16.0	2.5	DG	1
933	S-1401 (DG)	SMD Bobbin	ER-1406	LCP E4008	1	5x5	0.7x0.3	14.6 / 16.0	2.5	DG	2
934	S-1402 (DG)	SMD Bobbin	ER-1406	LCP E4008	1	6x6	0.7x0.35	14.6 / 16.0	2.5	DG	1
935	S-1402-1 (DG)	SMD Bobbin	ER-14.5/6	PM9630	1	6x6	0.7x0.35	14.6 / 16.0	2.5	DG	2
936	S-1402-2 (ZZ)	SMD Bobbin	ER-14.5/6	PM9630	1	6x6	0.7x0.35	14.6 / 16.0	2.5	ZZ	1
937	S-1403 (DG)	SMD Bobbin	POT-1408	LCP E4008	1	4x4	1.0x0.35	18.2 / 19.8	3.75	DG	1
938	S-1501 (DG)	SMD Bobbin	EFD-15	LCP E4008	1	5x5	0.7x0.4	18.2 / 21.35	2.5	DG	3
939	S-1501 (SZ)	SMD Bobbin	EFD-15	LCP E4008	1	5x5	0.7x0.4	17.6 / 19.5	2.5	SZ	0
940	S-1501-1 (DG)	SMD Bobbin	EFD-15	LCP E4008	1	5x5	0.7x0.4	18.2 / 21.35	2.5	DG	2

次へ: 資料総計:1033
