Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
961	S-1520 (SZ)	SMD Bobbin	EFD-15	PM9630	1	4x4	1.0x0.3	15.7 / 19.2 / 22.2	3.75	SZ	0
962	S-1701 (DG)	SMD Bobbin	EPC-17	PM9630	1	5x4	0.8x0.4	20.8 / 23.0	3.5 / 5.0	DG	5
963	S-1701 (SZ)	SMD Bobbin	EPC-17	PM9630	1	5x4	0.8x0.4	20.8 / 23.0	3.5 / 5.0	SZ	0
964	S-1901 (DG)	SMD Bobbin	EPC-19	PM9820	1	4x6	0.8x0.4	22.5 / 25.0	5.0 / 3.5	DG	4
965	S-1903-1 (SZ)	SMD Bobbin	EPC-19	LCP E4008	6	4x6	0.6x0.4	22.0 / 24.0	2.5 / 7.5	SZ	2
966	S-1904 (DG)	SMD Bobbin	EPC-19	LCP E4008	1	6x6	0.6x0.4	28.0	2.5	DG	2
967	S-1905 (DG)	SMD Bobbin	EPC-19	PM9630	1	6x6	0.6x0.4	21.9 / 23.9	2.5	DG	2
968	S-1906-1 (DG)	SMD Bobbin	EPC-19	LCP E4008	4	6x6	0.6x0.4	21.9 / 23.9	2.5	DG	2
969	S-2001 (DG)	SMD Bobbin	EFD-20	LCP E4008	6	6x3	0.7x0.3	24.1 / 26.9	2.5 / 6.25	DG	0
970	S-2003 (DG)	SMD Bobbin	EFD-20	PM9630	1	5x5	1.0x0.35	20.8 / 24.5 / 27.5	3.76	DG	3
971	S-2004 (DG)	SMD Bobbin	EFD-20	PM9630	1	5x5	1.0x0.4	23.1 / 25.1	3.76	DG	2
972	S-2005 (DG)	SMD Bobbin	EFD-20	PM9630	1	6x6	0.7x0.4	24.6 / 28.65	3.0	DG	8
973	S-2005-1 (DG)	SMD Bobbin	EFD-20	PM9630	1	6x6	0.7x0.4	28.0	3.0	DG	2
974	S-2005-2 (DG)	SMD Bobbin	EFD-20	LCP E4008	1	6x6	0.7x0.4	24.6 / 28.65	3.0	DG	1
975	S-2005-3 (SZ)	SMD Bobbin	EFD-20	PM9630	1	6x6	0.7x0.4	24.6 / 28.65	3.0	SZ	0
976	S-2501 (DG)	SMD Bobbin	EFD-25	PM9630	1	5x5	1.1x0.4	29.7 / 31.5	5.0	DG	6
977	S-2501 (SZ)	SMD Bobbin	EFD-25	PM9630	1	5x5	1.1x0.4	29.7 / 31.5	5.0	SZ	5
978	S-2501-1 (DG)	SMD Bobbin	EFD-25	PM9630	1	6x6	1.1x0.4	29.7 / 31.5	4.0	DG	1
979	S-2501-1 (SZ)	SMD Bobbin	EFD-25	PM9630	1	6x6	1.1x0.4	29.7 / 31.5	4.0	SZ	3
980	S-2502 (DG)	SMD Bobbin	EPC-25H	PM9630	1	5x6	1.0x0.4	26.3 / 28.7	3.5 / 5.0	DG	2

次へ: 資料総計:1033
