Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
241	P-1604-2 (DG)	TH Bobbin	EEL-16	T375J	1	4x6	ø0.6	12.2	3.5 / 2.7	DG	3
242	P-1604-4 (DG)	TH Bobbin	EEL-16	PM9630 JT	1	4x6	ø0.6	12.2	3.5 / 2.7	DG	0
243	P-1604-5 (DG)	TH Bobbin	EEL-16	PM9820 JR	1	4x6	ø0.6	12.2	3.5 / 2.7	DG	0
244	P-1606 (ZZ)	TH Bobbin	EE-16	T375J	1	3x3	ø0.6	9.0	3.0	ZZ	3
245	P-1607 (DG)	TH Bobbin	EE-16	T375J	1	6x4	ø0.6	12.2	2.7 / 3.5	DG	8
246	P-1607 (ZZ)	TH Bobbin	EE-16	T375J	1	6x4	ø0.6	12.2	2.7 / 3.5	ZZ	6
247	P-1607-1 (DG)	TH Bobbin	EE-16	T375J	1	6x4	ø0.6	12.2	2.7 / 3.5	DG	0
248	P-1607-2 (SZ)	TH Bobbin	EE-16	T375J / PM9823 / T200HF	1	6x4	ø0.6	12.2	2.7 / 3.5	SZ	6
249	P-1607-6 (DG)	TH Bobbin	EE-16	DAP AM113	1	6x4	ø0.6	12.2	2.7 / 3.5	DG	0
250	P-1607-7 (DG)	TH Bobbin	EE-16	DAP WH9100	1	6x4	0.5x0.5	12.2	2.7 / 3.5	DG	0
251	P-1607-8 (DG)	TH Bobbin	EE-16	DAP WH9100	1	6x4	ø0.6	12.2	2.7 / 3.5	DG	0
252	P-1607-9 (DG)	TH Bobbin	EE-16	T375HF	1	4x6	ø0.6	12.2	3.5 / 2.7	DG	0
253	P-1608 (DG)	TH Bobbin	UU-16H	PBT 4130	4	4x4	ø0.7	13.0	3.33	DG	4
254	P-1609 (DG)	TH Bobbin	BE-16H	T375J	2	4x4	0.5x0.5	12.7	2.54	DG	0
255	P-1609-3 (DG)	TH Bobbin	BE-16H	T375HF BK	2	4x4	0.5x0.5	12.7	2.54	DG	0
256	P-1611 (DG)	TH Bobbin	EI-16H	T375J	2	4x4	ø0.6	12.0	2.7 / 3.5	DG	3
257	P-1613 (SZ)	TH Bobbin	EI-16	PM9820	1	5x5	ø0.6	10.5	3.25	SZ	1
258	P-1613 (ZZ)	TH Bobbin	EI-16	PM9820	1	5x5	ø0.6 / 0.5x0.5	10.5	3.25	ZZ	10
259	P-1615 (DG)	TH Bobbin	EEL-16	T375J	1	6x6	ø0.6	12.0	2.7	DG	7
260	P-1616 (DG)	TH Bobbin	EE-16H	T375J	4	6x6	0.5x0.5	12.5	2.5	DG	4
