Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
61	P-0402 (DG)	TH Bobbin	RM-04	PM9630	2	3x3	ø0.45	7.2 / 10.8	1.8 / 3.6	DG	2
62	P-0402-1 (DG)	TH Bobbin	RM-04	PM9630	2	3x3	ø0.45	7.2 / 10.8	1.8 / 3.6	DG	2
63	P-0404 (DG)	TH Bobbin	RM-04	PM9630	2	3x3	ø0.5	7.2 / 10.8	1.8 / 3.6	DG	4
64	P-0404-1 (DG)	TH Bobbin	RM-04	PM9630	1	3x3	ø0.5	7.2 / 10.8	1.8 / 3.6	DG	1
65	P-0501 (DG)	TH Bobbin	RM-05	PM9630	1	3x3	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	7
66	P-0501-1 (DG)	TH Bobbin	RM-05	PM9630	2	3x3	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	4
67	P-0501-2 (DG)	TH Bobbin	RM-05	PM9630	1	4x4	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	0
68	P-0501-2 (SZ)	TH Bobbin	RM-05	PM9630	1	4x4	ø0.5	10.8 / 14.4	1.8 / 3.6	SZ	1
69	P-0501-3 (DG)	TH Bobbin	RM-05	PM9630	1	3x3	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	4
70	P-0502 (DG)	TH Bobbin	RM-05	PM9630	1	4x4	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	2
71	P-0502-1 (DG)	TH Bobbin	RM-05	PM9630	2	4x4	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	1
72	P-0504 (DG)	TH Bobbin	RM-05	PM9630	1	2x2	ø0.5	10.8	3.6	DG	3
73	P-0504 (SZ)	TH Bobbin	RM-05	PM9820 / PM9630	1	2x2	ø0.5	10.8	3.6	SZ	0
74	P-0504 (ZZ)	TH Bobbin	RM-05	PM9630	1	2x2	ø0.5	10.8	3.6	ZZ	6
75	P-0505 (DG)	TH Bobbin	RM-05	PM9630	2	2x2	ø0.5	10.8	3.6	DG	1
76	P-0509 (DG)	TH Bobbin	RM-05	PM9630	2	3x3	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	4
77	P-0509-1 (DG)	TH Bobbin	RM-05	PM9630	1	3x3	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	2
78	P-0509-2 (DG)	TH Bobbin	RM-05	PM9630	1	3x3	ø0.5	10.8 / 14.4	1.8 / 3.6	DG	0
79	P-0601 (DG)	TH Bobbin	RM-06	PET FR530	1	4x4	ø0.6	15.2	3.81 / 5.08	DG	2
80	P-0601-1 (DG)	TH Bobbin	RM-06	PET FR530	1	4x4	0.5x0.5	15.2	3.81 / 5.08	DG	2
