Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
81	P-0601-2 (DG)	TH Bobbin	RM-06	PET FR530	1	4x4	ø0.6	15.24	3.81 / 5.08	DG	2
82	P-0601-2 (SZ)	TH Bobbin	RM-06	PET FR530	1	4x4	ø0.6	15.24	3.81 / 5.08	SZ	2
83	P-0601-3 (DG)	TH Bobbin	RM-06	PF2736	1	4x4	ø0.6	15.2	3.81 / 5.08	DG	1
84	P-0602 (DG)	TH Bobbin	RM-06	PM9630	1	3x3	ø0.6	14.4 / 18.0	1.8 / 3.6	DG	0
85	P-0603 (DG)	TH Bobbin	RM-06	PM9630	1	3x3	ø0.5	14.4 / 18.0	1.8 / 3.6	DG	3
86	P-0603 (SZ)	TH Bobbin	RM-06	PM9630	1	3x3	ø0.5	14.4 / 18.0	1.8 / 3.6	SZ	0
87	P-0604 (DG)	TH Bobbin	RM-06	PM9630	1	3x3	ø0.5	14.4 / 18.0	1.8 / 3.6	DG	3
88	P-0604 (SZ)	TH Bobbin	RM-06	PM9630	1	3x3	ø0.5	14.4 / 18.0	1.8 / 3.6	SZ	2
89	P-0604 (ZZ)	TH Bobbin	RM-06	PM9630	1	3x3	ø0.5	14.4 / 18.0	1.8 / 3.6	ZZ	3
90	P-0604-1 (DG)	TH Bobbin	RM-06	PM9630	2	3x3	ø0.5	14.4 / 18.0	1.8 / 3.6	DG	2
91	P-0604-1 (SZ)	TH Bobbin	RM-06	PM9630	2	3x3	ø0.5	14.4 / 18.0	1.8 / 3.6	SZ	1
92	P-0604-2 (DG)	TH Bobbin	RM-06	PM9630	2	3x3	0.4x0.4	14.4 / 18.0	1.8 / 3.6	DG	0
93	P-0606 (DG)	TH Bobbin	RM-06	PM9630	1	NULL	NULL	NULL	NULL	DG	1
94	P-0607 (SZ)	TH Bobbin	RM-06	PET FR530	1	4x4	ø0.6	15.24	3.81 / 5.08	SZ	2
95	P-0701 (DG)	TH Bobbin	EP-07	PM9630	1	3x3	ø0.6	5.08	2.54	DG	4
96	P-0701-1 (DG)	TH Bobbin	EP-07	PM9630	1	3x3	0.5x0.5	5.08	2.54	DG	2
97	P-0702 (DG)	TH Bobbin	EP-07	PM9630	1	3x3	ø0.6	5.08	2.54	DG	2
98	P-0702-2 (DG)	TH Bobbin	EP-07	PM9630	1	3x3	ø0.6	5.08	2.54	DG	1
99	P-0702-3 (DG)	TH Bobbin	EP-07	PM9630	1	3x3	0.5x0.5	5.08	2.54	DG	1
100	P-0703 (DG)	TH Bobbin	EP-07	PM9630	1	3x3	0.4x0.4	5.08	2.54	DG	1
