Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
101	P-0705-1 (DG)	TH Bobbin	EP-07	PM9630	1	3x3	0.5x0.5	5.08	2.54	DG	0
102	P-0707-1 (DG)	TH Bobbin	EP-07	PM9630	1	2x2	ø0.5	5.08	5.08	DG	0
103	P-0708 (DG)	TH Bobbin	EPX-07	PM9630	1	4x4	0.7x0.3	7.4	2.5	DG	7
104	P-0709 (DG)	TH Bobbin	EP-07	PM9630	2	3x3	ø0.6	5.08	2.54	DG	2
105	P-0709-1 (DG)	TH Bobbin	EP-07	PM9630	2	3x3	0.5x0.5	5.08	2.54	DG	1
106	P-0710-2 (DG)	TH Bobbin	EP-07	PM9630	2	3x3	ø0.6	5.08	2.54	DG	0
107	P-0711 (DG)	TH Bobbin	EP-07	PM9630	2	2x2	ø0.6	5.08	5.08	DG	2
108	P-0713 (SZ)	TH Bobbin	RM-07	PM8375	1	NULL	NULL	NULL	NULL	SZ	3
109	P-0801 (DG)	TH Bobbin	EE-08.3	PM9820	1	3x3	ø0.5	6	2.5	DG	7
110	P-0802 (DG)	TH Bobbin	RM-08	PM9630	1	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	3
111	P-0802-1 (DG)	TH Bobbin	RM-08	PM9630	1	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	0
112	P-0802-2 (DG)	TH Bobbin	RM-08	PM9630	1	6x6	0.5x0.5	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	1
113	P-0802-4 (DG)	TH Bobbin	RM-08	PM9630	1	6x6	0.5x0.5	14.4 / 18.0 / 21.6	1.8 / 3.6 / 7.2	DG	1
114	P-0803 (DG)	TH Bobbin	RM-08	PET FR530	1	6x6	0.64x0.64	20.32	3.81 / 5.08	DG	5
115	P-0804 (DG)	TH Bobbin	RM-08	PM9630	2	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	1
116	P-0804-1 (DG)	TH Bobbin	RM-08	PM9630	1	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	1
117	P-0804-2 (DG)	TH Bobbin	RM-08	PM9630	1	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	1
118	P-0805 (DG)	TH Bobbin	RM-08	PM9630	2	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	1
119	P-0806 (DG)	TH Bobbin	RM-08	PM9630	1	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	3
120	P-0809 (DG)	TH Bobbin	RM-08	PM9630	2	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	DG	1
