Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
121	P-0811 (DG)	TH Bobbin	RM-08	PM9630	1	NULL	NULL	NULL	NULL	DG	1
122	P-0813 (DG)	TH Bobbin	EE-08.3	PM9820	2	2x2	ø0.5	6	5	DG	6
123	P-0813-2 (SZ)	TH Bobbin	EE-08.3	PM9820	2	2x2	ø0.5	6	5	SZ	1
124	P-0814 (DG)	TH Bobbin	EE-08.3	PM9820	2	2x2	ø0.5	6.8	5	DG	6
125	P-0814-2 (DG)	TH Bobbin	EE-08.3	PM9820	2	2x2	0.4x0.4	6.8	5	DG	0
126	P-0814-3 (SZ)	TH Bobbin	EE-08.3	PM9820	2	2x2	ø0.5	6.8	5	SZ	3
127	P-0814-4 (SZ)	TH Bobbin	EE-08.3	PM9820	2	3x2	ø0.5	6.8	2.5 / 5.0	SZ	0
128	P-0814-5 (DG)	TH Bobbin	EE-08.3	PM9820	2	2x2	ø0.5	6.8	5	DG	0
129	P-0816 (DG)	TH Bobbin	EE-08.3	PM9820	1	2x2	ø0.5	6.8	5	DG	2
130	P-0817 (DG)	TH Bobbin	EE-08.8	LCP E4008	2	2x2	0.5x0.5	15	6.5	DG	5
131	P-0820 (SZ)	TH Bobbin	EE-08.3	PM9820	1	2x2	ø0.5	6	5	SZ	0
132	P-0822 (DG)	TH Bobbin	EE-08.3	LCP E4008	2	2x2	0.4x0.3	6.8	5	DG	1
133	P-0826 (SZ)	TH Bobbin	RM-08	PM9630 / PM9820	1	6x6	0.6x0.6	23.32	3.81 / 5.08	SZ	1
134	P-0827 (SZ)	TH Bobbin	RM-08	PM9820	1	NULL	NULL	NULL	NULL	SZ	1
135	P-0829 (SZ)	TH Bobbin	RM-08	PM9630	1	6x6	ø0.6	14.4 / 18.0 / 21.6	3.6 / 7.2	SZ	0
136	P-0831 (SZ)	TH Bobbin	RM-08	PM9630	1	2x2	ø0.8	18.0	7.4 / 6.4	SZ	2
137	P-0832 (DG)	TH Bobbin	RM-08	PM9820	1	6	ø0.6		3.5 / 7.1	DG	2
138	P-0833 (ZZ)	TH Bobbin	RM-08	PM9820	1	3x2	0.5x0.5	14.4 / 16.2 / 17.95	1.8 / 3.5	ZZ	PE
139	P-0902 (DG)	TH Bobbin	ER-0905	LCP E4008	1	3x3	0.5x0.5	10.16	2.54	DG	2
140	P-0903 (DG)	TH Bobbin	POT-0905	PET FR530	1	NULL	NULL	NULL	NULL	DG	1

頁次：資料總數：1037
