Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
321	P-1907 (DG)	TH Bobbin	EI-18.6	PET FR530	1	3x3	0.64x0.64	20.32	5.0	DG	2
322	P-1908 (DG)	TH Bobbin	EE-19H	T355J	2	6x4	ø0.7	12.0	2.7 / 3.5	DG	2
323	P-1909 (DG)	TH Bobbin	EI-19	T375J	1	3x3	ø0.7	15.0	4.0	DG	2
324	P-1910 (DG)	TH Bobbin	EPC-19	PM9630	4	6x6	0.6x0.4	21.6	2.5	DG	1
325	P-1912 (DG)	TH Bobbin	EEL-19	T375J	1	5x5	ø0.8	24.1	3.5 / 4.5	DG	4
326	P-1912-3 (DG)	TH Bobbin	EEL-19	T375HF	1	5x5	ø0.8	24.1	3.5 / 4.5	DG	0
327	P-1914 (DG)	TH Bobbin	EI-19	PM9820	1	4x4	ø0.6	10.0	5.0	DG	3
328	P-1915-1 (DG)	TH Bobbin	EEL-19	T375J	1	4x6	ø0.6	12.0	3.5 / 2.7	DG	6
329	P-1915-2 (DG)	TH Bobbin	EEL-19	T375J	1	4x6	ø0.6	12.0	3.5 / 2.7	DG	1
330	P-1916 (DG)	TH Bobbin	EPC-19H	LCP E4008	6	6x6	0.6x0.4	21.2	2.5	DG	2
331	P-1922 (DG)	TH Bobbin	EI-19	PBT 4130	1	4x4	ø0.7	12.4	3.9 / 5.1	DG	2
332	P-1923 (DG)	TH Bobbin	EE-19	PET FR530	1	4x4	0.64x0.64	12.7	3.81 / 5.08	DG	4
333	P-1928 (SZ)	TH Bobbin	EE-19	PBT 1403G3	2	4x4	0.64x0.64	12.9	3.8 / 5.0	SZ	1
334	P-1946 (DG)	TH Bobbin	EE-19	PM9630	1	6x6	ø0.6	10.0	4.0 / 3.0 / 2.5 / 4.5	DG	1
335	P-1950 (DG)	TH Bobbin	EE-19	T375J / PM9820	1	5x4	ø0.6	12.5	4.0 / 5.0	DG	1
336	P-2001 (DG)	TH Bobbin	EF-20	PET FR530	1	3x3	0.64x0.64	10.0	5.08	DG	0
337	P-2001-1 (DG)	TH Bobbin	EF-20	PM9630JT	1	3x3	0.64x0.64	10.0	5.08	DG	0
338	P-2001-2 (DG)	TH Bobbin	EF-20	PET FR530	1	3x3	0.5x0.5	10.0	5.08	DG	1
339	P-2001-3 (DG)	TH Bobbin	EF-20	PET FR530	1	3x3	0.64x0.64	10.0	5.08	DG	1
340	P-2001-5 (DG)	TH Bobbin	EF-20	PM9820	1	3x3	0.64x0.64	10.0	5.08	DG	0

頁次：資料總數：1037
