Bobbin & Base

Part No.

Pin Size

Grooves

No.	Part No.	Type	Core Type	Meterial	Grooves	Pins	Pin Size	Pin Row Distance	Pin Pitch	origin	ver
281	P-1626-1 (DG)	TH Bobbin	BE-16H	T375J	1	4x4	0.5x0.5	12.7	2.54	DG	0
282	P-1626-2 (DG)	T-H BOBBIN	BE-16H	T375HF	1	4X4	0.5x0.5	12.7	2.54	DG	0
283	P-1629 (DG)	TH Bobbin	EF-16	PET FR530	1	2x2	0.5x0.5	12.6	10.0	DG	3
284	P-1631 (DG)	TH Bobbin	EI-16	T355J	1	5x5	ø0.6	10.5	3.25	DG	1
285	P-1631-2 (DG)	TH Bobbin	EI-16	PM9630 JT	1	5x5	ø0.6	10.5	3.25	DG	0
286	P-1632 (SZ)	TH Bobbin	EE-16H	T735HF	1	4x4	ø0.6	11.0	3.0	SZ	6
287	P-1632 (ZZ)	TH Bobbin	EE-16H	PM9820	1	4x4	ø0.6	11.0	3.0	ZZ	3
288	P-1632-1 (ZZ)	TH Bobbin	EE-16H	PM9820	1	4x4	ø0.6	11.0	3.0	ZZ	1
289	P-1635 (SZ)	TH Bobbin	EF-16	PET FR530 / FR531	1	4x4	ø0.8	15.05	3.8 / 7.6	SZ	0
290	P-1635 (ZZ)	TH Bobbin	EF-16	PET FR530	1	4x4	ø0.8	15.05	3.8 / 7.6	ZZ	2
291	P-1641 (SZ)	TH Bobbin	EEL-16	PET CNN3030	1	6x4	ø0.6	12.0	2.7 / 3.5	SZ	2
292	P-1646 (DG)	TH Bobbin	EEL-16H	LCP E4008	8	4x6	ø0.5 / 0.45x0.45	22.0	2.5	DG	2
293	P-1649 (SZ)	TH Bobbin	EF-16	PA66 A3X2G7 / PET FR530 NC	1	5x4	0.64x0.64	15.0	3.75 / 7.5	SZ	2
294	P-1653 (DG)	TH Bobbin	EEL-16	T375J	1	6x4	ø0.6	12.2	2.7 / 3.5	DG	0
295	P-1654 (DG)	TH Bobbin	EE-16	CP-J-8800	1	5x5	ø0.7	19.5	3.25	DG	1
296	P-1654-1 (DG)	TH Bobbin	EE-16	PM9823	1	5x5	ø0.7	19.5	3.25	DG	0
297	P-1660 (DG)	TH Bobbin	UU-16	T355J	2	3x3	ø0.7	13.0	5.0	DG	1
298	P-1660-1 (DG)	TH Bobbin	UU-16	T375HF	2	3x3	ø0.7	13.0	5.0	DG	0
299	P-1703 (DG)	TH Bobbin	EP-17	PM9630	1	4x4	ø0.6	15.0	5.0	DG	2
300	P-1703-4 (DG)	TH Bobbin	EP-17	DAP AM113	1	4x4	0.5x0.5	15.0	5.0	DG	0
